5 Axis Bridge Saw Machine

cnc-bridge-sawing

6axis-bridge-saw-cnc 5-axis-bridge-saw-cutting-machine

The 5 axis bridge saw machine which everybody call cnc bridge sawing can cut hexagon, tile, diamond, spiral stair, helical stair, circular etc…

The Machine has ability to can be producing round table, spiral and helical stair, marble coffee ellipse table, 3d surface models, marble ceiling collection, wall tile, floor tile, marble moulding/profile, shower trays, marble fireplaces & surrounds etc…

Teknik Özellikler Technical Data
Model GSG-CNC5AX.
Maks. Hammadde Genişliği Max. Working Dim. 3,5x2metre
Maks. Kesim Kalınlığı Max. Cutting Thickness 10cm.
Maks. Tarama Kalınlığı Max. Milling Thickness 20cm.
Kafa Sayısı Cutting Heads1
Testere Çap Saw Blade Diameter 350-500mm.
Cutting Motor Power İşleme Motor Gücü 15 kw.
Ana Motor Hareket Cutting Head Movement 0-90°(angular)
Ana Motor Hareket Cutting Head Movement 360° (C)
Toplam Elektrik Total Installed Power 25kW.
Ağırlık Weight 6500kg.
Makine Ebatları Dimensions of Machine(cm) 600x300x350(h)

Optional: Galvanized frame, Software for Cad Control

Applications

how-make-cut-marble-ellipse marble-granite-step-stairs marble-profile-moulding marble-top-table granite-top-table
